RS232S17A
Rugged 2U Workstation
Field tested, failsafe and long life performance in extreme conditions.
Overview
About this platform.
As processing performance continues to improve, Crystal Group is dedicated to minimize the SWaP envelope of the RS232S17A. High-end computing performance in a 2U chassis with a depth under 17” (43.1 cm) fits most any rack space. This rugged workstation supports a variety of drive types, including large rotational drives. The RS232S17A provides high-performance computing and high-capacity data storage in a rugged, all-aluminum package, to withstand the harshest terrains and applications.
Technical detail
Know the platform.
- Light weight aluminum construction–20 to 24 lbs.
- Easily mounted — Delrin glides, fixed mount, or Jonathan® rails
- Up to 64 GB of memory
- Rugged 2U, rack mounted, short depth 17″
- Versatility with up to two removable 3.5” HDDs or four 2.5” SSDs
- Three full height expansion slots
RS232S17A technical specifications
| Form Factor | 2U |
|---|---|
| Height | 3.5” (8.89 cm) |
| Width | 17.5” (44.45 cm); EIA-310 Rack Compliant |
| Depth | 17” (43.2 cm) |
| Weight | 20-24 lbs (9.07-10.88 kg); content dependent |
| Mounting | Option 1: Mounted on Delrin glides; Option 2: Fixed mount, front and rear; Option 3: Jonathan rails |
| Power Supply | Option 1: 460W 120/240VAC 50/60Hz w/PFC, 115VAC 400Hz; Option 2: 505W 18-36VDC |
| CPU Architecture | Intel® Xeon® processor E3-1200 v6/v5, Intel® 7th/6th Gen; Core™ Series 12/13th Gen CPU options |
| Expansion | 1 PCI-E x16, 2 PCI-E x8 |
| External Bays | Option 1: Two removable SATA or SAS 2.5” or 3.5” HDD; Option 2: Four 2.5” SATA or SAS HDD; Option 3 (can be combined with HDD option): One CD/DVD/BD (R/W) |
| Cooling | Eight high speed, high volume fans CPU temperature controlled |
| System Board | Option 1: Supermicro X11SSZ-F; Option 2: Supermicro X11SSZ-TLN4F; Option 3: Supermicro X13SAZ-F/Q |
| MIL-STD-810, Operational Temperature, Method 501, Procedure I/II | -35°C to +60°C |
| MIL-STD-810, Storage, Method 501, Procedure I/II | -55°C to +85°C |
Configuration affects weight and available options. Confirm your required configuration with CoreTech.
