RS121S16
Rugged 1U Server
Lightweight, high-end computing system.
Overview
About this platform.
The RS121S16 rugged servers provide high-performance computing and high-capacity data storage in a rugged, all-aluminum package to withstand the roughest terrains and toughest applications. This short-depth, lightweight server has been tested to withstand challenging environments, meet, or exceed military and industrial standards, and provide the latest COTS technologies to best manage cost, availability, upgradability, and flexibility.
Technical detail
Know the platform.
- Light weight aluminum construction – 7 to 15 lbs.
- Full processor performance to +55°C
- Rugged 1U, rack mounted 16” depth
- Versatility with two or three removable 2.5″ sleds
- Expandable with PCIe x8 slot
- Intel® Xeon® D series processors
RS121S16 technical specifications
| Form Factor | 1U |
|---|---|
| Height | 1.75" (4.45cm) |
| Width | 16.5" (41.91cm) |
| Depth | 16" (40.64cm) |
| Weight | 7-15 lbs (3.18-6.8 kgs) |
| Mounting | Option 1: Mounted on Crystal glide rails; Option 2: Fixed mount, front and rear |
| Power Supply | 460W 120/240VAC 50/60Hz w/PFC, 115VAC 400Hz |
| CPU | Intel® Xeon® D-1500 series and 13th Gen Core Series CPU Options |
| Memory | Up to 128GB DDR4 |
| Expansion Slots | Two full height half-length PCIe x8 slots |
| External Bays | Option 1: Up to three removable SATA SSDs or HDDs, 7mm height; Option 2: Up to two removable SAS SSDs or HDDs, up to 15mm height; Option 3: 1x M.2 SATA/PCIe 3.0×4, non-removable; Option 4: Optical drive |
| System Board | Option 1: Xeon D-1587, 6x SATA 3, 2x 10GBE, VGA graphics, IPMI, 2x USB 3.0 rear, 1x USB 2.0 front; Option 2: Supermicro X13SAV-LVDS |
| Software Capability | Supports Windows 11®, Linux®, or Windows Server |
| MIL-STD-810, Storage, Method 501, Procedure I/II | -55°C to +85°C |
Configuration affects weight and available options. Confirm your required configuration with CoreTech.
