CoreTech / Rugged servers

RS1.532L21X2F

Rugged Twin Server

Increase readiness.

Request current datasheet

Overview

About this platform.

The RS1.532L21X2F 1.5U rugged server delivers proven reliability and computing performance in extreme and unpredictable environments—critical for successful execution of combat, sonar, and electronic warfare applications across all domains, including cyber.

The smaller, integrated footprint of the unit fits easily into standard rack slots. With system availability, superior cooling, and shock/vibe resistance, this 1.5U rugged server stands ready to perform.
Lives are on the line. Reliability matters. Warfighters achieve dominance with accurate, real-time information—which requires failsafe computer hardware that works in any conditions. That’s why all our products are engineered and tested to meet or exceed strict military standards.

In addition, our unsurpassed thermal performance uses custom heatsinking solutions and special air management techniques. Likewise, we meticulously fuse the unique GPU and networking capabilities with the latest Intel® Xeon® Scalable processors to deliver secure, near-zero latency at the tactical edge.
Combat-proven solutions you can trust. Fielding more than 17,500 servers for the U.S. Navy, Crystal Group solutions have demonstrated unmatched fielded reliability of greater than 99 percent. Key to our consistency is having the full design, development, testing and manufacturing team in-house. Using the latest COTS technologies for ease and speed of upgrades and reconfigurations, we’re able to deliver customized solutions that meet the unique needs of any program.
Industry-leading support. Crystal Group’s expert team and global network provide fast, effective product support around the clock and around the globe. With in-house or onsite technical assistance, industry-leading five-plus-year warranties, and exceptional service, you can depend on Crystal Group as a strategic partner, dedicated to your success.

Technical detail

Know the platform.

RS1.532L21X2F technical specifications

Form Factor 1.5U
Height 2.63" (6.67cm)
Width 17.5" (44.45cm)
Depth 21" (53.34cm)
Weight 24 - 32 lbs (10.89 - 14.51 kgs)
Power Supply Single 1500W power supply shared by both nodes. Operates on 90-264V AC (50/60Hz) or 180-350VDC input
CPU Up to 22 cores per socket (2 sockets per node, 4 total) up to 125W each, 2nd Gen Intel Xeon Scalable Processors
Memory 16 GB DDR4 ECC RDIMM/LRDIMM per node (2 nodes)
Expansion Slots 2x PCIe x16 HHHL low profile cards per node (4 total), 1x Supermicro SIOM card per node (2 total)
Cooling Seven high-speed, high-volume fans
Storage 2x U.2 NVMe SSD per node (4 total)
Software Capability Accepts Windows 10®, VMware®, Linux® or Windows Server®
MIL-STD-810, Operational Temperature -30°C to +45°C
MIL-STD-810, Storage, Method 501, Procedure I/II -40°C to +85°C
Electromagnetic Compatibility Designed to meet standard MIL-STD-461, RE102, CE102 compliant

Configuration affects weight and available options. Confirm your required configuration with CoreTech.
