RE1322 Rugged Embedded GPU Computer
A small embedded computer with room for a dual-width, low-profile graphics card, such as an NVIDIA RTX A2000 or RTX 4000 SFF Ada. 12th or 13th Gen Intel Core i7 processors, up to 64 GB of memory and up to three removable SSDs, in a carbon fiber chassis from 6.3 lb (2.9 kg). Built by Crystal Group and supplied in Israel by CoreTech.
Manufactured by
Built for Airborne systems
- Graphics
- Dual-width, low-profile card
- Processor
- 12th/13th Gen Intel Core i7
- Storage
- Up to 3 removable SSDs
- Temperature
- −40 °C to +60 °C
Applications
Where it fits.
The RE1322 is for platforms that need more GPU power than a small embedded computer usually allows, on the ground, in the air or in a fixed workstation. Its carbon fiber chassis is field-tested to withstand shock, vibration, extended temperatures and harsh environments, and it mounts on a tray or a bulkhead with the supplied ears.
- Ground mobile applications
- Airborne applications
- UAV and UGV applications
- Industrial workstations, fixed or mobile
- Video processing workstation, with rugged displays
Technical detail
Know the platform.
RE1322 technical specifications
| Height | 4.5" (11.43cm) |
|---|---|
| Width | 12" (30.48cm) |
| Depth | 9" (22.86cm); excluding connectors |
| Weight | 6.3-8.5 lbs. (2.9-3.86 kg) |
| CPU Architecture | 12th/13th Generation Intel® Core i7 CPU options |
| Expansion Slots | One PCIe slot for single or dual width cards |
| Internal Expansion Slots | Up to three SATA 2.5” SSD (externally removable) |
| Memory | Up to 64GB unbuffered, non ECC DDR4 1.2V SO-DIMM |
| Power Supply | 18-36 VDC |
| Cooling | Three high reliability 60mm fans |
| Mounting | Tray or bulkhead mounted using ears supplied |
| MIL-STD-810, Operational Temperature | -40°C to +60°C |
| MIL-STD-810, Storage, Method 501, Procedure I/II | -40°C to +85°C |
| MIL-STD-810, Humidity, Method 507, Procedure II | 240 hours with humidity kit |
| MIL-STD-810, Altitude, Method 500 | 12,500ft operation, 40,000ft transport |
Configuration affects weight and available options. Confirm your required configuration with CoreTech.
Configuration
Choose the right configuration.
Tell us which graphics card and software you plan to run and where the unit will be mounted, and we will come back with a configuration and a quotation.
| Processor | 12th or 13th Gen Intel Core i7 |
|---|---|
| Graphics | One PCIe slot for a single- or dual-width low-profile card, such as an NVIDIA RTX A2000 or RTX 4000 SFF Ada |
| Memory | Up to 64 GB DDR4 SO-DIMM (unbuffered, non-ECC) |
| Storage | Up to three externally removable 2.5" SATA SSDs: two 15 mm or three 7 mm drives |
| Power | 18–36 VDC |
| Cooling | Three high-reliability 60 mm fans |
| Mounting | Tray or bulkhead, using the supplied ears |
| Software | Windows 11, Windows Server, VMware or Linux |
| Size and weight | 4.5 in high, 12 in wide, 9 in deep excluding connectors (11.43 × 30.48 × 22.86 cm); 6.3–8.5 lb (2.9–3.86 kg) |
| Environment | Tested to MIL-STD-810 for operating temperature (−40 °C to +60 °C), storage temperature (−40 °C to +85 °C) and vibration (with a vibration kit). MIL-S-901 Grade A with solid-state drives and shock kits |
Why source it through CoreTech
- A local contact in Rishon LeZion, Israel, for quotations and technical questions.
- Every system is checked by CoreTech's technical team before delivery.
- Every system comes with a 5-year warranty.
- RMA cases are handled in Israel, and repairs are carried out in Israel by CoreTech's technical team.
- Lead times from about a week to a few months, depending on the configuration.
Questions
Common questions.
Which graphics cards fit in the RE1322?
Its PCIe slot takes a single- or dual-width low-profile card, such as an NVIDIA RTX A2000 or RTX 4000 SFF Ada.
Are the drives removable?
Yes. Up to three 2.5" SATA SSDs can be removed from outside: two 15 mm drives or three 7 mm drives.
How much memory does it take?
Up to 64 GB of DDR4 SO-DIMM.
What temperature range does it operate in?
−40 °C to +60 °C, tested to MIL-STD-810 Method 501. The storage range is −40 °C to +85 °C.
What is the difference between the RE1322 and the RE0412?
The RE1322 takes a dual-width graphics card, has up to three removable SSDs and runs on 18–36 VDC, at 6.3–8.5 lb (2.9–3.86 kg). The RE0412 is lighter, under 4.5 lb (2.04 kg), with one low-profile PCIe slot, an Intel Xeon D-1700 option with up to 128 GB of ECC memory, AC or DC power, and up to 16 TB on fixed drives.
What power does it need?
18–36 VDC.
What warranty do the systems have, and who handles RMA?
Every system comes with a 5-year warranty. CoreTech handles RMA cases in Israel, and repairs are carried out in Israel by its technical team.
How long does delivery take?
From about a week to a few months, depending on the configuration.
How do I get a quote in Israel?
Use “Request a quote” on this page, or call +972-73-3224235.
