RE1218M Rugged Secure Embedded Computer

A compact aluminum embedded computer that holds up to eight removable 2.5" drives and a PCIe x16 card, with security features such as TPM 2.0, FIPS 140-2 drives, intrusion detection, tamper evidence and instant data destruction. Intel Core processors, MIL-C-26482 circular connectors and 18–36 VDC or 36–75 VDC power. Built by Crystal Group and supplied in Israel by CoreTech.

Download datasheet (PDF)

Manufactured by Crystal Group

Built for Airborne systems

Storage
Up to 8 removable drives
Expansion
1 × PCIe x16
Temperature
−40 °C to +60 °C
Weight
13–18 lb (5.9–8.2 kg)

Applications

Where it fits.

The RE1218M is for space-challenged platforms that still need high-end workstation performance or serious storage. It mounts in any orientation, and its security features are there to protect critical data from attempted breaches at the edge.

  • Command and control
  • Communications
  • Intelligence, surveillance and reconnaissance (ISR)
  • Workstation in demanding environments

Technical detail

Know the platform.

RE1218M technical specifications

Height 4.1" (10.41 cm)
Width 10.1" (25.65 cm)
Depth 14.4" (36.58cm) excluding connectors
CPU Architecture Intel® Core™ Processors
Expansion Slots One PCIe x16
Cooling High speed, high volume thermostatically controlled fans, air over components cooling design
Memory Up to 64GB DDR4 SO-DIMM
Storage Up to eight removable 2.5” drives
Connections MIL-C-26482 military circular I/O connectors
Power Supply Option 1: 18-36VDC (200W) with MIL-STD-461 filtering, MIL-STD-704; Option 2: 36-75VDC (200W) with MIL-STD-461 filtering, MIL-STD-704
Mounting Fixed mount or tray mount
Software Capability Windows 11®, Windows Server®, VMWare®, Linux®
MIL-STD-810, Operational Temperature -40°C to +60°C, with solid state drives
MIL-STD-810, Storage, Method 501, Procedure I/II -55°C to +85°C

Configuration affects weight and available options. Confirm your required configuration with CoreTech.

Configuration

Choose the right configuration.

Tell us about the platform, the storage and security you need, and the power available, and we will come back with a configuration and a quotation.

Processor Intel Core
Memory Up to 64 GB DDR4 SO-DIMM
Storage Up to eight removable 2.5" drives
Expansion One PCIe x16 card
Security Features include TPM 2.0, FIPS 140-2 solid-state drives, intrusion detection, tamper evidence and instant data destruction
I/O MIL-C-26482 military circular connectors
Power 200 W at 18–36 VDC or 36–75 VDC, with MIL-STD-461 filtering, to MIL-STD-704
Cooling High-speed, high-volume, thermostatically controlled fans, with air over the components
Mounting Fixed or tray mount, in any orientation
Software Windows 11, Windows Server, VMware or Linux
Size and weight 4.1 in high, 10.1 in wide, 14.4 in deep excluding connectors (10.41 × 25.65 × 36.58 cm); 13–18 lb (5.9–8.16 kg) depending on the cards
Environment Tested to MIL-STD-810 for operating temperature (−40 °C to +60 °C with solid-state drives), storage temperature (−55 °C to +85 °C), vibration (7.18 GRMS on the x and y axes, 4.63 GRMS on z) and shock (20 g functional, 40 g crash hazard). Humidity, altitude and MIL-STD-461 CE102/RE102 are listed with testing in progress

Why source it through CoreTech

  • A local contact in Rishon LeZion, Israel, for quotations and technical questions.
  • Every system is checked by CoreTech's technical team before delivery.
  • Every system comes with a 5-year warranty.
  • RMA cases are handled in Israel, and repairs are carried out in Israel by CoreTech's technical team.
  • Lead times from about a week to a few months, depending on the configuration.

Questions

Common questions.

How much storage does the RE1218M hold?

Up to eight removable 2.5" drives.

Which security features does it have?

Its features include TPM 2.0, FIPS 140-2 solid-state drives, intrusion detection, tamper evidence and instant data destruction.

What power does it need?

200 W at 18–36 VDC or 36–75 VDC, with MIL-STD-461 filtering, to MIL-STD-704.

What temperature range does it operate in?

−40 °C to +60 °C with solid-state drives, tested to MIL-STD-810 Method 501. The storage range is −55 °C to +85 °C.

Which processor and memory does it use?

Intel Core processors, with up to 64 GB of DDR4 SO-DIMM memory.

How can it be mounted?

Fixed or on a tray, in any orientation.

What warranty do the systems have, and who handles RMA?

Every system comes with a 5-year warranty. CoreTech handles RMA cases in Israel, and repairs are carried out in Israel by its technical team.

How long does delivery take?

From about a week to a few months, depending on the configuration.

How do I get a quote in Israel?

Use “Request a quote” on this page, or call +972-73-3224235.
