CoreTech / Rugged switches
RCS1120FW
Rugged Firewall
Overview
About this platform.
Using Cisco COTS architecture, the RCS1120FW VPN-capable firewall provides both rugged and critical cybersecurity protection for seamless, high-performance computing in harsh, unpredictable forward-deployed environments.
With an IPS throughput of 2.6 Gbps that does not require extra hardware, this firewall is built to withstand extreme temperatures, moisture, shock, vibration and other challenging conditions. This solution provides unmatched versatility, standards for industry-leading technology, and reliable protection of critical networks in a rugged form factor.
Technical detail
Know the platform.
RCS1120FW technical specifications
| Height | 1.75" (4.45 cm) |
|---|---|
| Width | 17.5" (44.5 cm) |
| Depth | 12" (30.5 cm) |
| Weight | Less than 10 lbs (4.5 kg); estimated |
| Mounting | Fixed mount (front and rear) |
| Power Supply | 85-264 VAC, auto switching |
| Cooling | Four high-speed, high-volume fans |
| Stateful inspection throughput | 4.5 Gbps |
| IPS Throughput | 2.6 Gbps (extra hardware module not required) |
| Concurrent sessions | 200,000 |
| IPSec VPN throughput | 1.2 Gbps |
| Maximum VPN Peers | 150 |
| Integrated I/O | 8-port 1000 Base-T; 4x SFP |
| MIL-STD-810, Operational Temperature, Method 501/502 Procedure I/II | -15°C to +50°C |
| MIL-STD-810, Storage, Method 501, Procedure I/II | -25°C to +55°C |
Configuration affects weight and available options. Confirm your required configuration with CoreTech.
